Discharge Through Venturimeter

Note: Price is based on given specs. For other specifications, please submit an inquiry.

Discharge through a venturimeter is a fundamental concept in fluid mechanics and flow measurement. A venturimeter is a highly reliable and accurate device used to measure the flow rate (discharge) of fluids flowing through a closed pipe. It works on the principle of Bernoulli’s theorem, which establishes the relationship between pressure energy, kinetic energy, and potential energy of a flowing fluid.

Venturimeters are widely used in engineering laboratories, industrial pipelines, water supply systems, chemical plants, oil & gas industries, power plants, and research institutions. Due to their high accuracy and low energy loss, venturimeters are preferred over many other flow-measuring devices.

Trusted scientific equipment providers like scilabex.com and Scilabstore supply high-quality venturimeter apparatus suitable for PAN India and international delivery, making them a reliable choice for laboratories and industries worldwide.

What is Discharge Through Venturimeter?

Discharge through a venturimeter refers to the volume of fluid flowing per unit time through a pipe where a venturimeter is installed. The discharge is calculated by measuring the pressure difference between the inlet section and the throat section of the venturimeter.

As the fluid enters the converging cone of the venturimeter, its velocity increases and pressure decreases. At the throat, velocity becomes maximum and pressure minimum. This pressure difference is used to determine the discharge using standard mathematical relations.

Principle of Venturimeter

The venturimeter operates on Bernoulli’s principle, which states:

For an incompressible, steady-flowing fluid, the total energy per unit weight remains constant along a streamline.

In simple terms, when fluid velocity increases, pressure decreases, and vice versa. This pressure-velocity relationship helps calculate the discharge accurately.

Construction of a Venturimeter

A venturimeter consists of three main parts:

1. Converging Cone – Gradually reduces the pipe diameter, increasing fluid velocity.

2. Throat – The narrowest section where velocity is maximum and pressure is minimum.

3. Diverging Cone – Gradually increases the diameter to recover pressure with minimal energy loss.

Pressure tapping points are provided at the inlet and throat to measure pressure difference using a manometer or pressure sensor.

Working of Venturimeter

• Fluid enters the venturimeter with a certain velocity and pressure.

• As it flows through the converging section, velocity increases and pressure drops.

• At the throat, maximum velocity and minimum pressure are achieved.

• The pressure difference between inlet and throat is measured.

• Using Bernoulli’s equation and continuity equation, discharge is calculated.

This method ensures high accuracy and repeatability, making venturimeters ideal for precise flow measurements.

Formula for Discharge Through Venturimeter

The theoretical discharge is given by:

$$Q = C_d \times \frac{A_1 A_2}{\sqrt{A_1^2 - A_2^2}} \times \sqrt{2gh}$$

Where:

• $Q$ = Discharge

• $C_d$ = Coefficient of discharge

• $A_1$ = Area at inlet

• $A_2$ = Area at throat

• $g$ = Acceleration due to gravity

• $h$ = Differential head

Key Features of Venturimeter

• High accuracy in flow measurement

• Very low head loss

• Long service life

• Suitable for large diameter pipes

• Works efficiently with clean fluids

• Minimal maintenance required

Advantages of Venturimeter

• Accurate and reliable results

• Low pressure loss compared to orifice meters

• Suitable for continuous flow measurement

• Ideal for high-velocity fluid flow

• Long-term stable performance

Where is Discharge Through Venturimeter Used?

Venturimeters are used in multiple sectors, including:

1. Engineering & Educational Laboratories

• Fluid mechanics experiments

• Practical demonstrations for students

• Research and academic projects

2. Water Supply Systems

• Municipal water distribution

• Pumping stations

• Irrigation pipelines

3. Industrial Applications

• Chemical processing plants

• Oil & gas pipelines

• Power generation plants

• Pharmaceutical industries

4. HVAC & Utilities

• Flow measurement in heating and cooling systems

• Industrial utilities management

Countries Where Venturimeter is Widely Used

Venturimeters are globally accepted and used in:

• India

• USA

• Canada

• Germany

• UK

• UAE

• Saudi Arabia

• Australia

• Singapore

• South Africa

With international delivery services, Scilabstore and scilabex.com support global laboratories and industries with premium-quality flow measurement equipment.

Why Choose Scilabex & Scilabstore?

• ✔ Trusted scientific equipment supplier

• ✔ High-quality laboratory-grade instruments

• ✔ PAN India delivery available

• ✔ International shipping supported

• ✔ Suitable for education, research, and industry

• ✔ Reliable after-sales support

Both scilabex.com and Scilabstore are known as trusted companies delivering precision-engineered instruments that meet international quality standards.

Frequently Asked Questions (FAQs)

Q1. What is discharge in a venturimeter?

Discharge is the volume of fluid flowing per unit time through the venturimeter-installed pipe.

Q2. Which principle is used in venturimeter?

Venturimeter works on Bernoulli’s principle.

Q3. Why is venturimeter more accurate than orifice meter?

Because it has lower energy loss and better pressure recovery.

Q4. Can venturimeter be used for international projects?

Yes, venturimeters supplied by Scilabstore are suitable for global standards and international use.

Q5. Is venturimeter suitable for laboratory experiments?

Absolutely, it is one of the most important apparatus in fluid mechanics laboratories.
